Horizontal flowrappers SEH 025
GENERAL DESCRIPTION
- Horizontal flowwrapper with servo-driven sealing jaws equipped with a lugged conveyor
- Specifically designed for modified atmosphere packaging or for working with specific films
- Options : Automatic splicer, electrical photocell for printing registration, modified atmosphere, coder, powered feed roll, gusseting devices, pack defating devices, no product / no bag, out of position, no cut, stop of jaws closing for out of phase product, easy opening package, outfeed packs control, outfeed conveyor extension, stainless steel version
TECHNICAL DATA
- Product dimensions:
-Width: max 350 mm / 13,78''
- Height: max 180 mm / 7.09 "
- Reel dimensions:
- Reel width: 520 mm / 20,47''
- Outside diameter: max 350 mm / 13,78''
- Core diameter: 70 ÷ 76 mm / 2,76'' - 2,99''
- Machine dimensionsDimensions : 4990 x 1500 x 1960 mm
196.46" x 59.06" x 77.17
- Weight: 1300 kg
- Packaging materials: heat-sealable, coated, cold-sealable, polyethylene
UP TO 60 PPM/MIN
Specific version for modified atmosphere packaging
Additional information
| Machine speed | |
|---|---|
| Final packaging | |
| Your product | Bakery, Chocolate factory, Convenience food, Frozen products, Fruits & Vegetables, Meat, Non-food product, Pastry |
